• 640 × 512 thermal resolution, high sensitivity detector, NETD< 35 mK (25°C, F# = 1.0)
• Image processing technology: Adaptive AGC, DDE, 3D DNR
• 1024 × 768 resolution 0.39-inch OLED display
• Supports distance measurement and hotspot function
• Supports video recording and snapshot, built-in EMMC (16 GB)
• Supports digital zoom and reticle function, palettes of color adjustable
• Observation Distance up to 1800 m

KEY FEATURES

• Thermal Module
• Image Sensor Uncooled Focal Plane Array
• Max. Resolution 640 × 512
• Frame Rate 50 Hz
• Pixel Interval 12 μm
• Response Waveband 8 μm to 14 μm
• NETD < 35 mK (25°C, F# = 1.0)
• Lens (Focal Length) 35 mm
• Detection Range 1800 m
• Field of View 12.52° × 10.03°
• Min. Focusing Distance 2 m
• Aperture F1.0
• Magnification 1.82×
• Image Display
• Display 1024 × 768, 0.39 inch, OLED
• Image Mode Black Hot, White Hot, Red Hot, Fusion
• FFC (Flat Field Correction) Mode Auto, Manual, External Correction
• Exit Pupil 6 mm
• Eye Relief 45 mm
• Diopter (Range) -5 D to 3 D
• System
• Digital Zoom 1×, 2×, 4×, 8×
• Capture Snapshot Yes
• Record Video On-board video recording
• Standby Mode Yes
• Storage Built-in EMMC (16 GB)
• PIP Yes
• DPC Yes
• Hotspot Yes
• Uniformity Correction Auto, Manual, External Correction
• Hot Track Yes
• Reticle Yes
• Power Supply
• Battery Type One Rechargeable Lithium battery
• Battery Operating Time 5 hours continuous running (@25°C, Wi-Fi and CVBS off)
• Battery Capacity Display Yes
• Anti-reverse Battery Connection Yes
• Overvoltage Protection Yes
• Type-C Power Supply
• 5 V DC/2 A, USB Type-C interface3
• Supports external power supply
• General
• Work Temperature/Humidity -30°C to 55°C (-22°F to 131°F)
• Protection Level IP67
• Dimension 200.38 × 66.32 × 87.10 mm (7.89 × 2.61 × 3.43 inch)
• Weight < 518 g without eyepiece and batteries
• Port Type-C
• Laser Rangefinder
• Safety Class for Laser Class 1
• Wavelength 905 nm
• Max. Measuring Range 600 m
• Measurement Accuracy ± 1 m
• Min. Measuring Range 10 m
