The ROK Wiring Harness is specifically designed for installing ROK Work Lights, including the ROK 10, 20, and 40 models. This 12-volt wiring kit features a 40-amp relay and a fully terminated two-pin waterproof Deutsch connector, ensuring reliable and durable connections in various weather conditions. The kit also includes an illuminated switch for easy operation and an inline fuse rated at 5 amps for added safety. With cable lengths tailored for convenient installation—2.3 meters from the relay to the Deutsch connector, 1.2 meters from the relay to battery ring terminals, and 1.3 meters from the relay to the switch—this harness provides a straightforward solution for powering your work lights.

KEY FEATURES

Voltage: 12V

Relay Rating: 40 amps

Connector Type: 2-pin waterproof Deutsch connector

Fuse Rating: 5 amps

Cable Lengths:

• Relay to Deutsch connector: 2.3 meters
• Relay to battery ring terminals: 1.2 meters
• Relay to switch: 1.3 meters

Switch Connections:

• Pin 1: Blue - Power Out
• Pin 2: Red - Power In
• Pin 3: Black - Ground (for LED illumination)

Kit Inclusions:

• 1 x Wiring harness
• 1 x Instructions
