How does the 16 mm SUS303 stainless steel Disc-Lok spigot perform under heavy rifle recoil during rapid PRS strings?

The 16 mm SUS303 stainless steel Disc-Lok spigot pairs with auto-gated locking clamp adapters to form a rigid, high-strength connection specifically engineered to withstand severe recoil forces from heavy magnums and precision calibres without slipping. This locking architecture ensures zero torsional play, maintaining your point of aim across rapid competition strings.

Is the Spartan Hercules Tripod suitable for lightweight backcountry alpine hunting in Australia?

At 5.0 lb (~2.27 kg), the Hercules is deliberately over-engineered for maximum rigidity and recoil absorption rather than ultralight mobility. If your primary Australian hunting style involves multi-day backcountry alpine trekking where every gram counts, lighter platforms such as the Spartan Hoplite or Ascent Gen 2 with MagnaSwitch are better recommended.

What is the operating height range and terrain adaptability of the Hercules Tripod for outback shooting positions?

The tripod provides a highly stable shooting platform ranging from a low prone height of 9.5 inches (24.1 cm) up to 62.5 inches (158.8 cm) for full standing shots. It features four selectable leg pitch angles, tungsten carbide tips with tethered synthetic rubber boots, and an included Dyneema ballast basket to dampen vibrations in windy Australian outback conditions.

What adapters and mounting systems are natively compatible with the Hercules Tripod's integrated ball head?

The integrated 38 mm ball head comes equipped with a 16 mm Disc-Lok spigot module that natively connects to Spartan Disc-Lok adapters, including HD Picatinny and HD Arca-Swiss adapters. Additionally, the modular head unit can accommodate Spartan's optional 12 mm MagnaSwitch spigot and pan-head converters depending on your preferred rifle attachment method.

Shooting Tripod - Spartan SPAR03040R

The Spartan Precision Equipment Hercules Tripod (Disc-Lok Spigot Model) is a heavy-duty mechanical shooting support engineered for high-energy precision rifles and heavy-calibre shooting. Constructed from CNC-machined 7075-T7351 aerospace-grade billet aluminium and multi-layered carbon fibre, the system delivers rigid stability across an operating height range of 9.5 inches to 62.5 inches (24.1 cm to 158.8 cm). It features an integrated 38 mm ball head equipped with a 16 mm SUS303 stainless steel Disc-Lok spigot, providing a secure, high-strength interface designed to withstand severe recoil forces without slipping during competitive or field shooting.

Key Features

Disc-Lok Spigot Architecture: Uses a 16 mm SUS303 stainless steel spigot paired with auto-gated locking clamp adapters to maintain a rigid, slip-free connection under heavy-recoil impulses.
Integrated 38 mm Ball Head: Features a low-profile design with an ergonomic friction control lever for continuous 360-degree panning, elevation, and cant adjustments.
Multi-Position Modular Legs: Four selectable leg pitch angles accommodate shooting positions from low prone to full standing, with detachable carbon fibre legs utilizing M14x1.5 modular threads for conversion into trekking poles or shelter supports.
Environmental Stability: Outfitted with tungsten carbide feet protected by tethered synthetic rubber boots, alongside an included Dyneema ballast basket for wind dampening on uneven Australian terrain.
Modular Compatibility: Connects natively with Spartan Disc-Lok adapters (including HD Picatinny and HD Arca-Swiss interfaces) and accepts optional 12 mm MagnaSwitch spigots or pan-head converters.

Specifications

Weight: 5.0 lb (~2.27 kg)
Height Range: 9.5 in to 62.5 in (~24.1 cm to 158.8 cm)
Chassis Material: CNC-machined 7075-T7351 aerospace-grade billet aluminium
Leg Construction: Multi-layered carbon fibre with M14x1.5 modular thread
Interface Module: 16 mm SUS303 stainless steel Disc-Lok spigot
Ball Head Diameter: 38 mm
Footing: Tungsten carbide tips with tethered synthetic rubber boots
Power Requirements: Non-powered mechanical hardware (0V / no battery required)

Who is the Spartan Hercules Tripod Disclok Spigot for?

Precision Rifle Series (PRS) and Extreme Long Range (ELR) competitors — requires the severe recoil resistance of the 16 mm SUS303 stainless steel Disc-Lok spigot and a wide 9.5-inch to 62.5-inch height range to transition rapidly between positional barricades and prone stages.
Long-range tactical precision rifle shooters — relies on the 5.0 lb (2.27 kg) chassis mass and integrated 38 mm ball head to maintain zero movement and smooth 360-degree cant and elevation tracking when firing heavy magnum calibres.
Stationary big-game hunters and vehicle-based pest controllers — utilizes the M14x1.5 modular thread leg system and rigid 5.0 lb (2.27 kg) carbon-and-aluminium build to anchor large-calibre rifles for sustained fixed-position shooting.

Less suitable for: Backcountry alpine hunters prioritising ultralight pack weight, where a 5.0 lb (2.27 kg) heavy-duty shooting platform adds unnecessary bulk compared to lightweight, compact modular hunting tripods designed primarily for rapid field deployment.

SKU	SPA39631LP
Model #	SPAR03040R
Brand	Spartan
Shipping Weight	1.0000kg
