What rifle rails are compatible with the Sportsmatch ATP94 scope mounts?

The Sportsmatch ATP94 mounts are engineered to fit standard 20mm Weaver and Picatinny rails. They are specifically designed to securely clamp onto these rails while providing an adjustable platform for 34mm scope tubes.

How much vertical elevation adjustment do these mounts provide for long-range shooting?

The ATP94 features a built-in vertical elevation adjustment of up to 50 MOA. This mechanical adjustment allows long-range shooters and hunters to keep their scope's internal turrets centered near their optical sweet spot, avoiding image degradation caused by extreme internal adjustments.

Are there any Australian electrical safety certifications like SAA or RCM required for this product?

No, because the Sportsmatch ATP94 is an entirely mechanical hunting and shooting accessory containing no electrical components, wiring, batteries, or power supplies, standard Australian electrical safety considerations and RCM certifications do not apply.

What are the recommended torque settings for installing the ATP94 mounts safely?

For proper installation and to ensure structural integrity under heavy recoil in the harsh Australian outback, you should tighten the scope ring screws to 2.0 Nm (18 in-lbs) and the mount-to-rail clamping screws to 3.1 Nm (27.4 in-lbs).

Adjustable Scope Mounts - Sportsmatch ATP94

The Sportsmatch Weaver 2 Piece Adjustable 34mm High Scope Mounts (Model: ATP94) offer a precision-engineered, heavy-duty mounting solution designed to meet the demands of long-range shooters and hunters. Manufactured in the UK, these high-tensile mounts are specifically engineered to fit standard 20mm Weaver and Picatinny rails, accommodating scopes with a 34mm body tube diameter. The standout feature of the ATP94 is its vertical elevation adjustability of up to 50 MOA. This allows shooters to make mechanical elevation adjustments directly at the mount, keeping the scope's internal turrets centered near their optical sweet spot to preserve image quality and resolution at extreme distances. Equipped with a removable steel recoil stop pin, this mounting system provides rock-solid security against heavy recoil on centrefire, rimfire, and spring-piston air rifles.

Key Features:

Elevation Adjustability: Offers up to 50 MOA of vertical elevation adjustment to compensate for physical barrel-to-receiver alignment discrepancies or to preserve optical clarity at long range.
Heavy-Duty Construction: Manufactured in the United Kingdom from high-tensile materials, ensuring maximum structural integrity and reliable performance under harsh field conditions.
Secure Dual-Screw Clamping: Features a robust double-screw clamping system on the base that locks the vertical adjustment securely in place.
Recoil Protection: Includes a removable steel recoil stop pin (arrestor pin) to prevent mount movement on high-recoil rifles.
Optic Preservation: Keeps the scope's internal erector tube centered, avoiding the optical degradation caused by maxing out turret adjustments.

Technical Specifications:

Model: Sportsmatch ATP94
Tube Diameter Compatibility: 34mm
Rail Compatibility: 20mm Weaver and Picatinny rails
Height (Dimension A - Rail to bottom of ring): Adjustable from 20mm to 21.5mm (0.787 to 0.846 inches)
Ring Width (Dimension B): 21mm (0.827 inches)
Maximum Objective Lens Diameter: Up to 56mm (up to 60mm on select rifle configurations)
Product Weight: 130 grams
Elevation Adjustment Range: Up to 50 MOA
Scope Ring Torque Setting: 2.0 Nm (18 in-lbs)
Mount-to-Rail Torque Setting: 3.1 Nm (27.4 in-lbs)

Who It's For:

The Sportsmatch ATP94 scope mounts are designed for Australian long-range precision shooters, target sports enthusiasts, and regional pest control operators. If you are shooting at extreme distances or dealing with barrel-to-receiver alignment discrepancies (barrel droop) common in high-powered air rifles and older centrefire platforms, these adjustable mounts provide the mechanical correction needed without exhausting your scope's internal elevation travel. Built to withstand the rugged environmental conditions of the Australian outback, the ATP94 is a dependable choice for professional vermin hunting and competitive shooting disciplines where absolute precision and physical durability are required.

SKU	SPM39120LP
Model #	ATP94
Brand	Sportsmatch
Shipping Weight	1.0000kg
