The Nocpix VISTA H35R LRF Thermal Monocular combines advanced thermal imaging with built-in rangefinding precision, making it a powerful tool for hunters, wildlife observers, and tactical users. Equipped with a 640×512 thermal sensor (12μm pixel pitch) and <15mK NETD sensitivity, it delivers crystal-clear imagery and sharp target differentiation, even in fog, rain, or total darkness.

The F/0.9 35mm lens captures more light for superior detail, while the Reality+ AI image algorithm reduces pixilation and enhances clarity during zoom. With 3–28× magnification and built-in image stabilization, the Vista H35R offers smooth, jitter-free viewing across its full 1800m detection range.

Its integrated 1200m laser rangefinder pairs with a ballistic calculator, providing real-time shooting solutions for unmatched long-range accuracy. A vivid 2560×2560, 1.03-inch OLED display ensures immersive and detailed visuals, with six customizable colour palettes for different hunting environments.

Durable and IP67 waterproof, the Vista H35R is designed for field use in harsh weather. Lightweight at just 640g, it features a silent button system for discreet operation and up to 5.5 hours of runtime with a replaceable 18650 battery. With 64GB storage, you can capture photos, videos, and audio, while the NOCPIX App enables livestreaming, file management, and software updates directly from your smartphone.

Compact, rugged, and precise—the Nocpix Vista H35R is the ultimate thermal monocular for serious hunters.



KEY FEATURES



• Thermal Sensor: 640×512, 12μm pixel pitch, NETD <15mK
• Lens: 35mm F/0.9, gathers more light for clearer imaging
• Magnification: 3–28× with Reality+ AI image enhancement
• Detection Range: Up to 1800m
• Laser Rangefinder: Built-in, accurate to 1200m with ballistic calculator
• Display: 2560×2560 AMOLED, 1.03-inch screen for immersive clarity
• Frame Rate: 60Hz for smooth, real-time observation
• Colour Palettes: Six modes including White Hot, Black Hot, Fusion, Red Hot, Green Monochrome, and Red Monochrome
• Recording: Photo, video, and audio capture with 64GB internal storage
• Stabilization: Built-in image stabilization for steady viewing
• Durability: IP67 waterproof and dustproof
• Battery: Replaceable 18650, up to 5–5.5h runtime
• Compact Design: Lightweight at 640g, silent operation buttons
• Connectivity: Wi-Fi + NOCPIX App for livestreaming and updates

Full Technical Specifications

• Sensor Type: Thermal
• Sensor Resolution: 640×512
• Pixel Pitch: 12 μm
• NETD: <15mK
• Frame Rate: 60Hz
• Lens Diameter: 35mm F/0.9
• Magnification: 3× – 28×
• Detection Range: 1800m
• Field of View (H×V): 12.5° × 10.0° / 22° × 18°
• Exit Relief: 25mm
• Laser Rangefinder: Yes, up to 1200m
• Ballistic Calculator: Yes
• Display: AMOLED, 1.03-inch, 2560×2560 resolution
• Storage: 64GB internal memory
• Recording: Photo, video, audio
• Battery: Replaceable 18650, 4400mAh pack
• Battery Life: ~5–5.5h (at 22°C)
• Water Resistance: IP67
• Operating Temperature: -20°C to +50°C
• Video Output: Digital video
• Dimensions: 190 × 67 × 79 mm
• Weight: 640g (with battery)
