Will the Redding 33242 Decapping Rod Assembly fit my Redding Type-S Bushing Die in .243 Winchester?

No, this assembly is specifically designed for standard Redding conventional sizing dies such as the Full Length and Deluxe series. It is not compatible with Redding Type-S Bushing Dies or Competition Dies, which require different decapping components.

Does this decapping rod assembly work with small flash hole target brass?

It is designed for standard 0.080 inch (2.0 mm) boxer primer flash holes. If you are reloading brass with small or undersized 1.5 mm flash holes, standard pins may bind or bend unless specific small-hole pins are used.

What sub-components are included in the Redding 33242 package?

This genuine Redding replacement part includes the decapping rod (Part #01033), a standard expander or size button (Part #39242) with a 0.243 inch diameter, and a standard decapping pin (Part #01060), all constructed from heat-treated steel.

Do I need any special firearms licenses to purchase this reloading accessory in Australia?

No, this is a standalone mechanical reloading component and is non-restricted under Australian state and territory firearms legislation, meaning you do not need a firearms license to buy or possess it.

Can I upgrade the expander button on this assembly to a carbide version for high-volume reloading?

Yes, the threaded design allows you to easily swap the standard steel expander button for optional upgrades such as the Redding carbide size button (#48242) or tapered expander (#19242) to reduce friction during high-volume sizing sessions.

Decapping Rod Assembly - Redding 33242

The Redding 33242 Decapping Rod Assembly is a precision-machined, heat-treated steel replacement component engineered for Redding conventional full-length and neck-sizing dies. Chambered specifically for .243 Winchester cartridges, this assembly deprimes spent Boxer primers while simultaneously expanding the internal case neck using an integrated 0.243 in expander button. Its modular, threaded construction allows handloaders to service damaged decapping pins or worn expander balls without replacing the complete sizing die assembly.

Key Features

Dual-Action Processing: Deprimes spent boxer primers and expands internal case necks to factory-specified diameter in a single sizing press stroke.
Modular Serviceability: Threaded steel rod construction allows direct replacement of individual components, including the decapping pin (Part #01060), decapping rod (Part #01033), and size button (Part #39242).
Calibre-Specific Profiling: Fitted with a standard 0.243 in (6mm) expander ball to ensure precise neck tension on .243 Winchester brass.
Upgrade Compatibility: Accommodates optional Redding accessories, including #19242 tapered expanders and #48242 carbide size buttons.

Specifications

Product Name: Redding Decapping Rod Assembly (.243 Winchester)
Model / Part Number: 33242
Calibre Compatibility: .243 Winchester
Expander Ball Diameter: 0.243 in (6mm)
Material: Heat-treated, precision-machined steel
Included Sub-Components: Decapping Rod (#01033), Standard Expander Button (#39242), Standard Decapping Pin (#01060)
Flash Hole Compatibility: Standard 0.080 in (2.0 mm) Boxer primer flash holes
Die Compatibility: Redding Conventional Sizing Dies (Full Length #80114, Deluxe #84114, Premium #66114)

Who is the Redding 33242 Decapping Rod Assembly for .243 Winchester for?

Reloaders loading .243 Winchester ammunition on Redding conventional sizing dies — requires a dedicated 0.243 in expander ball to set consistent internal case neck dimensions during routine resizing on standard Redding sizing dies.
Handloaders replacing damaged decapping pins or expander buttons in Redding sizing dies — restores factory functionality to bent or worn decap components using a complete assembly engineered specifically for standard .243 Winchester die bodies.

Less suitable for: Handloaders running cases with undersized 1.5 mm target flash holes or using Redding Type-S Bushing Dies and Competition Dies; these setups require small-diameter decapping pins or dedicated bushing die decapping rod assemblies lacking fixed expander buttons.

SKU	RD102261LP
Model #	33242
Brand	Redding
Shipping Weight	0.2000kg
